Availability: In Stock / Ready to Ship
| Specification | Z 100 Series | Z 125 Series | Z 150 Series | Z 200 Series | Z 250 Series | Z 300 | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10010 | 10012 | 10015 | 12510 | 12512 | 12515 | 15015 | 15019 | 20015 | 20019 | 20024 | 25019 | 25024 | 30024 | |
| Thickness T (mm.) | 1.0 | 1.2 | 1.5 | 1.0 | 1.2 | 1.5 | 1.5 | 1.9 | 1.5 | 1.9 | 2.4 | 1.9 | 2.4 | 2.4 |
| Depth D (mm.) | 100 | 125 | 150 | 200 | 250 | 300 | ||||||||
| Flange E (mm.) | 50 | 50 | 65 | 75 | 85 | 95 | ||||||||
| Flange F (mm.) | 45 | 45 | 60 | 70 | 80 | 90 | ||||||||
| Lip L (mm.) | 18 | 18 | 18 | 18 | 24 | 24 | ||||||||
| Weight (kg/m.) | 1.78 | 2.12 | 2.66 | 1.93 | 2.36 | 2.97 | 3.63 | 4.53 | 4.48 | 5.59 | 7.06 | 6.88 | 8.65 | 10.28 |
